Shipment Inspection, Sorting & Data Tracking
Radio Frequency IDentification ON-RFID
RFID tracking for item-level records.
- Features
- RFID tag reading for garments
- Supports inventory tracking and production data management
- Links inspection results to individual items
- Helps build product history records
- Supports traceability and quality control workflows
- Suitable for smart garment production data integration
Description
ON-RFID is suitable for garment production, inspection, and shipment workflows where item-level RFID tag reading is required. It can be used when factories need to track product movement, inspection records, or shipment status. This device helps convert manual records into digital data, making inventory status, production history, and shipment records easier to search and manage. ON-RFID can be connected with ON-688CD6S / ON-688CDD6S needle detectors, ON-CM barcode readers, ON-5 sorting systems, and OMW carton inspection systems to build a workflow from inspection and data reading to shipment tracking.
Specifications
| Model | ON-RFID |
|---|---|
| Power Supply | 1P AC220V 50/60Hz |
| Rated Power (kW) | 0.2 |
| Detection Channel Height (mm) | 100 |
| Detection Channel Width (mm) | 600 |
| Conveyor Speed (m/min) | 30 |
| Detection Method | Radio Frequency Identification |
| Machine Dimensions L × W × H (mm) |
1600 × 900 × 950 |
| Packing Dimensions L × W × H (mm) |
1650 × 950 × 1100 |
| N.W. / G.W. (kg) | 120 / 180 |
Model: ON-RFID
| Power Supply | 1P AC220V 50/60Hz |
|---|---|
| Rated Power | 0.2 kW |
| Detection Channel Height | 100 mm |
| Detection Channel Width | 600 mm |
| Conveyor Speed | 30 m/min |
| Detection Method | Radio Frequency Identification |
| Machine Dimensions | 1600 × 900 × 950 mm |
| Packing Dimensions | 1650 × 950 × 1100 mm |
| N.W. / G.W. | 120 / 180 kg |
*Design and specifications subject to change without prior notice.
