Random-Size Carton Side Sealing OSZ-50XN
Random-size lidded box side sealing in 15 seconds.
- Features
- Suitable for lidded boxes in different sizes
- Sealing time of approximately 15 seconds per box
- Suitable for flat cartons and foam boxes
- Used for mixed-size carton side sealing
- Suitable for packaging lines with changing order sizes
- Applicable to warehouse shipment and logistics distribution workflows
Description
OSZ-50XN is suitable for packaging sites where carton sizes change and side sealing is required. It is especially suitable for lidded boxes, flat cartons, and foam boxes. Compared with same-size side sealing machines, OSZ-50XN is more suitable for multi-product, mixed-size, or order-based shipment workflows. When different products use different box dimensions, this machine can be placed after packing to complete the side sealing process. For mixed-size lidded box shipment workflows, the downstream line can connect with barcode, RFID, and automatic routing equipment.
Specifications
| Model | OSZ-50XN |
|---|---|
| Power Supply | 220V, 50/60Hz |
| Air Supply | 5–6 kg/m², 150 L/min |
| Conveyor Speed | 240 boxes/h |
| Working Height (mm) | 600 |
| Tape Size (mm) | 50–70 |
| Applicable Carton Size | According to the design drawing |
| Machine Dimensions L × W × H (mm) |
2100 × 1300 × 1500 |
| N.W. (kg) | 450 |
| Other | This machine must be used with an air compressor. |
Model: OSZ-50XN
| Power Supply | 220V, 50/60Hz |
|---|---|
| Air Supply | 5–6 kg/m², 150 L/min |
| Conveyor Speed | 240 boxes/h |
| Working Height | 600 mm |
| Tape Size | 50–70 mm |
| Applicable Carton Size | According to the design drawing |
| Machine Dimensions | 2100 × 1300 × 1500 mm |
| N.W. | 450 kg |
| Other | This machine must be used with an air compressor. |
*Design and specifications subject to change without prior notice.
